LM Vertical Roller Mill

Input Size

0-55mm

Capacity

3-700TPH

LM Vertical Mill integrates with drying, pulverizing and powder-selection. It can be widely applied in cement, chemical, coal and electric power industries. It gets more and more popular in the pulverizing industry.

MATERIAL

Calcite

Bentonite

Bauxite

Barite

Slag

Gypsum

Kaolin

Limestone

SPECIFICATION

LM-M Vertical Coal Mill Series

LM-K Vertical Mine Mill Series

LM-N Vertical Slag Mill Series (Slag Micropowder Preparation)

LM-N Vertical Refractory Grinding Series (Refractory Materials with High Alumina and High Silicon Content such as Slag)

LM-Y Vertical Pre-Grinding Series

LM-X Vertical Fine Grinding Mill

CASES

200,000TPY Quicklime Grinding Plant in Hubei

80,000TPY Quicklime Grinding Plant in Anhui

120,000TPY Quicklime Grinding Plant in Shanxi

Get Solution & Price Right Now!

Leave your information below to get customized
solutions and free quote!

Grinding Feed Particle Size(mm)	<20
Raw Coal Moisture	<15%
Coal Powder Fineness	R0.08=10-20%(80-90% passing through 200 mesh)
Coal Powder Moisture	≤1-5%
Capacity(t/h)	4-6
Main Motor Power(kW)	55-75

Grinding Feed Particle Size(mm)	<20
Raw Coal Moisture	<15%
Coal Powder Fineness	R0.08=10-20%(80-90% passing through 200 mesh)
Coal Powder Moisture	≤1-5%
Capacity(t/h)	7-10
Main Motor Power(kW)	90-132

Grinding Feed Particle Size(mm)	<30
Raw Coal Moisture	<15%
Coal Powder Fineness	R0.08=10-20%(80-90% passing through 200 mesh)
Coal Powder Moisture	≤1-5%
Capacity(t/h)	10-17
Main Motor Power(kW)	185-200

Grinding Feed Particle Size(mm)	<30
Raw Coal Moisture	<15%
Coal Powder Fineness	R0.08=10-20%(80-90% passing through 200 mesh)
Coal Powder Moisture	≤1-5%
Capacity(t/h)	15-22
Main Motor Power(kW)	220-280

Grinding Feed Particle Size(mm)	<30
Raw Coal Moisture	<15%
Coal Powder Fineness	R0.08=10-20%(80-90% passing through 200 mesh)
Coal Powder Moisture	≤1-5%
Capacity(t/h)	20-30
Main Motor Power(kW)	280-355

Grinding Feed Particle Size(mm)	<30
Optimal Moisture Content for Grinding Feed	<4%
Moisture of Grinding Feed Requiring Drying	<15%
Finished Product Fineness	0.84-0.037mm(20-400mesh)
Finished Product Moisture	≤1%
Capacity(t/h)	10-40
Main Motor Power(kW)	200-220

Slag Moisture	<15%
Slag Specific Surface Area	≥400m²/kg
Product Moisture	<1%
Capacity(t/h)	7-15
Main Motor Power(kW)	200-250

Grinding Feed Particle Size(mm)	≤30
Grinding Feed Moisture(%)	≤3%
Product Particle Size(≤0.08mm)	≥25%
Product Particle Size(≤2mm)	≥80%
Material Throughput(t/h)	30-80
Main Motor Power(KW)	200-220

Grinding Feed Particle Size(mm)	≤35
Grinding Feed Moisture(%)	≤3%
Product Particle Size(≤0.08mm)	≥25%
Product Particle Size(≤2mm)	≥80%
Material Throughput(t/h)	40-150
Main Motor Power(KW)	400-450

Grinding Feed Particle Size(mm)	≤40
Grinding Feed Moisture(%)	≤3%
Product Particle Size(≤0.08mm)	≥25%
Product Particle Size(≤2mm)	≥80%
Material Throughput(t/h)	60-300
Main Motor Power(KW)	800-900

Grinding Feed Particle Size(mm)	≤50
Grinding Feed Moisture(%)	≤3%
Product Particle Size(≤0.08mm)	≥25%
Product Particle Size(≤2mm)	≥80%
Material Throughput(t/h)	130-500
Main Motor Power(KW)	1800-2500

Grinding Feed Particle Size(mm)	≤55
Grinding Feed Moisture(%)	≤3%
Product Particle Size(≤0.08mm)	≥25%
Product Particle Size(≤2mm)	≥80%
Material Throughput(t/h)	160-600
Main Motor Power(KW)	2500-2800

Grinding Feed Particle Size(mm)	<10
Moisture Content of Grinding Feed(%)	<4%
Finished Product Fineness(10-40μm)	90-97%
Capacity(t/h)	3-9
Main Motor Power(KW)	160-200
